6 PERSON LUXURY SUBMARINE

personal small private submarines Aurora 6 person model side view.

SPACIOUS COMFORTABLE UNDERWATER LOUNGES

The AURORA 6 person model offers a very spacious environment for the occupants as well as giving excellent underwater field of views. The submarine’s cabin is arranged in four segments enhancing privacy with the pilot at the front, the owner’s lounge right behind, the guests’ lounge in the rear, and the private emergency restroom in the back hull compartment. The large acrylic hyper-hemispheres have a large inside diameter for both the Owners’ Lounge and for the Guests’ lounge segments. The submarine’s interior configuration provides the Owners Lounge’s convertible seating with long lounge chair configuration and associated upholstery details. The Guest Lounge provides spacious room for the three occupants with swivel seats such that they can orient themselves sideways for a better view on either side. The large entry hatch and spacious interior of the submarine in conjunction with the convertible seating arrangements also allows for comfortable boarding for all the occupants.

personal small private submarines Aurora 6 side view.

COMFORTABLE BOARDING
Aurora 6 submarine cutout view of boarding arrangements.

GRACEFUL & SAFE BOARDING

SEAmagine's innovative Aurora technology is a new approach to the design of a personal luxury submarine, maximizing the field of view of the private submarine and providing an unparalleled vista. The occupants from this private luxury submarine have a view, unobstructed by top hatches and side pontoons that provide the sensation of entering the underwater world, as opposed to simply observing it. When floating at surface this luxury submarine has a high freeboard making a stable platform for people to walk on. The AURORA-6 provides a comfortable boarding arrangement with telescopic handrails on the upper deck, a large entry hatch, sufficient space with rotating chairs and convertible seating that gives spacious room for the occupants to move to their seats. This well thought out innovative design ensures safety and comfort for boarding and exiting the personal submarine from yachts even in less than ideal sea conditions.




6 PERSON ELEGANT ARRANGEMENTS
personal small private submarines Aurora 5 person model front view.

UNDERWATER EXPERIENCE WITH PRIVACY

The AURORA 6 person luxury submarine can seat 5 passengers and 1 pilot with personal comfort and a good level of privacy for the owners. The space inside the submersible is configured optimally with four segmented compartments. The pilot cockpit at the front has an excellent navigation viewpoint. The owners have their own segment with two first class seating arrangements. The guests in the rear segment have three rotating seats and allow them to view each side of the submarine as the dives progresses. The rear hull compartment has an emergency restroom which can be closed off for privacy.

personal small private submarines Aurora 6 person model front view.

personal small private submarines Aurora 6 side view.

AURORA-6 SUBMARINE TECHNICAL OVERVIEW

6 PERSON MODEL - ABS Classed Submarines - 300m to 1000m Depth Rated



GENERAL SUBMERSIBLE SPECIFICATIONS

seamagine aurora 6 person specs sheet. AURORA-6 PERSONAL SUBMARINE SPECIFICATION

GENERAL
Designer / Manufacturer SEAmagine Hydrospace Corporation
Model AURORA-6
Number of Occupants 5 Passengers + 1 Pilot
Maximum Operating Depth 300m (984 ft) to 1000m (3300 ft)
Classification ABS or DNV-GL
Additional Approval Cayman Islands Shipping Registry
DIMENSIONS
Length 5.93 m (233 in)
Width 2.90 m (114 in)
Height 2.31 m (91 in)
Dry Weight 14,500 Kg (32,000 lbs)
Size and Weight Can Be Customized
Cabin Payload 600 Kg (1320 lbs)
Hatch Diameter 0.75 m (30 inches)
Hoist Arrangement Two Point Hoist
PROPULSION
Maximum Speed 3 Knots
Propulsion Type DC Electric, Venturi Shaped Thrusters
Horizontal Propulsion 4 x 10HP Thrusters
Vertical Propulsion 2 x 10HP Thrusters
Propulsion Mission Time 8 Hours
LIFE SUPPORT SYSTEM
Mission Time 8 Hours
Reserve Capacity 96 Hours
Oxygen Monitoring Dual O2 Sensors
CO2 Monitoring Dual CO2 Sensors
Oxygen Delivery System Flow Control
Backup Breathing Systems Standalone Independent Units
POWER CAPACITY
Battery Type Lithium Type
Total Power Capacity 40 KWH
Charging Time 5 - 7 Hours


INCLUDED WITH PRIVATE SUBMARINE

ABS or DNV-GL Classification
Underwater Communication System for Private Submersible and Topside
Topside USBL (Ultra Short Baseline) Private Sub Tracking Hand Carry Console
Dual Frequency Forward Looking Sonar
5 X LED Flood Lights
Doppler Velocity Log (DVL) Navigation on Personal Submersible
USBL GPS Navigation Software on Private Submersible
External Wet Joystick for Surface Handling
Private Submarine Battery Charger
Color Customized to Client's Request


OPTIONAL ADDITIONAL EQUIPMENT

Robotic Manipulators Arms 5 to 7 Axis Models
Underwater HD Video Systems with Pan and Tilt Units
SEAmagine 360 Degree Underwater HD Camera System
...More Additional Subsea Equipment Available Upon request


Expert Training & Technical Support Program

SEAmagine provides a well-structured pilot training program for this personal luxury submarine, evolved over many years and initially developed in conjunction with the US Coast Guard. The program includes technical support during the submarine's initial setup on its yacht followed by the training of the submersible pilots and support crew to handle personal submersible operations and its general maintenance. SEAmagine provides a comprehensive technical support program after the delivery and initial training which involves an annual onsite overall checkup by SEAmagine engineers on all aspects of the submarine to ensure safety and continued reliability..

Aurora-6 lounges description image.

Aurora 6 Person Personal Luxury Submarine For Yachts
